GLIDE RACK
REMOVING AND REPLACING RACKS
STEP 2
Push rack assembly in until the front hang tabs hit the front rods of the side
supports. Slightly lift the front of the rack assembly, and slide in further until the
rods are in between the openings on the front hang tabs. Push the front of the
rack assembly down until the rack assembly is in-place.
STEP 1
Extend the left and right glides at the same length, and hold rack and glides, one
on each side. Choose rack position and locate rear hang tabs on the left and
right glides and place on the left and right rack side supports.
Rack Side Support
Rear Hang Tab
Front Hang Tab
