23
ameriwoodhome.com
STEP
17
9
(x4)
#A80250
9
10
E
E
finished
edge
finished
edge
(x4)
#A80480
Insert the four shelf supports (9) into the shelf support holes
in the partitions (A&B).
Insert the four shelf supports with pin (10) into the shelf
support holes in the legs.
When inserting the shelf support with pin (10), make sure the
pointed pin is pointing up. The pointed pin will insert into the
holes in the bottom of adjustable shelf (E).
B
A
9
10
To Next Page
