Ameriwood HOME 1816096COM - Step-by-Step Assembly; Step 1: Prepare Part A

7
ameriwoodhome.com
STEP
1
Proper orientation of CAM LOCK
Tip
Assembly
Quick
1
3
4
(x2)
#A22620
(x2)
#A21660
(x3)
#A22920
3
1
4
1
4
4
You will need to tap the connector (4)
with a hammer to fully insert. Be sure
the connector is positioned as shown
before tapping into hole.
3
A
