STEP9
*rawedgesareshaded
endview
Turnthescrewclockwise
tolockinplace.
Notice:Smallreferenceholewill
beatthetopendofthemolding.
Presstherightfrontmolding(G)againsttherightpanel(B)sothe
connectorbolts(4)engagetheconnectors(3).Turnthescrewinthe

centeroftheconnector(3)clockwisetolockinplace.
3
B
G
