Ameriwood HOME 5319340EBL - Page 8

8
ameriwoodhome.com
STEP
1
Proper orientation of CAM LOCK
Tip
Assembly
Quick
1
3
5
(x2)
#A22620
(x2)
#A22900(white)
#A22920(black)
(x1)
#A21660
Youwillneedtotaptheconnector
(3)withahammertofullyinsert.
Besuretheconnectorispositioned
asshownbeforepushingintohole.
5
1
3
3
A
