STEP
11
4
Tube
You
× 2
1
× 2
2
Ø6 x 25mm
Ø8 x 30 mm
× 2
9
Ø15 x 12mm
F
H
4.1 Attach (1) to (H) as illustrated. Do NOT over tighten.
4.2 Attach (H) to (F) & (G) with (2) & (9) as illustrated.
Assembly
UNLOCK
LOCK
Tip
Quick
Proper orientation of CAM LOCK
H
1
9
2
Proper alignment
F
H
