STEP
13
6
Tube
You
6.1 Attach (F) & (G) to (C) with (2) & (9) as illustrated.
× 4
2
Ø8 x 30 mm
× 4
9
Ø15 x 12mm
C
F
G
2
9
Assembly
UNLOCK
LOCK
Tip
Quick
Proper orientation of CAM LOCK
