STEP
27
20
20.1 Un-fold the door hinge (12).
20.0 Attach (V) to (D) & (W) to (E) with (6) as illustrated.
V
W
6
D
E
× 16
6
Ø3.5 x 14 mm
12
UN-FOLD
12
Instruction for door
position adjustment
is shown at Step 27
(Page 34).
