Ameriwood HOME Ashton Lane 1674096WCOM - Page 7

Part List
Tube
You
Hardware Bag Reference Number:
21674096WCOM0SF
Actual Size
ameriwoodhome.com
7
× 50
Cam bolt
TSF0355
1
× 71 × 4
Screw
TSF0813
Ø4 x 30 mm
× 24
Screw
TSF0805
× 4
Bolt
TSF1810
2
3
6
Ø6 x 25mm
8
Wood dowel
TSF0501
Ø8 x 30 mm
Ø3.5 x 14 mm
Ø5/32" x 19mm
Not Actual Size
× 50
Cam lock
TSF0302
Spare: 2 pcs
9
× 2 × 8
Shelf support
TSF0557
× 4
Hinge
TSF2722
10
11
Ø15 x 12mm
Handle
TSF2221
51 x 23 x 20 mm
WARNING
ADVERTENCIA
AVERTISSEMENT
× 1
Warning label
TSF2913
13
× 11
Screw
TSF0815
Ø4 x 40 mm
4
× 12
Screw
TSF0816
Ø4 x 50 mm
5
× 20
Screw
TSF1201
7
Ø3.5 x 14 mm
12
Note: #2 Phillips-head screwdrivers (not provided)
is needed for the assembly.
