STEP
9
2
Tube
You
× 2
2
Ø8 x 30 mm
C
2
5
K
K
2.1 Attach (K) to (C) with (2) & (5) and make sure the cam lock holes face to the
same side as illustrated.
× 4
Ø4 x 50 mm
5
Cam lock hole
orientation
Cam lock hole
orientation
