STEP
1
Tube
You
*rawedgesareshaded
Note: This unit should be assembled on a clean surface.
This bed can be assembled with the drawers on the right side of the bed or the left side. This step shows both options. The
Head Board (A) has square corners and Foot Board (F) has curved corners. These parts have drilling to attach the slides (16) for
both options. The rest of this assembly manual shows the drawers on the left side of the Headboard as shown in the bottom right
view.
Drawers on right side of Headboard:
Drawers on left side of Headboard:
A A
F
F
To Next Page
