Ameriwood HOME Twin Mates Bed 5321340EBL - Step 4: Connect Center Support

14
ameriwoodhome.com
STEP
4
Tube
You
1
6
11
16a
16b

Refertopage3forcamlock&camboltprocedureifneeded.
Alignthethreeholesincentersupport(E)withthreeholesin
theslides(16a)and(16b).
Finished Edge
(x4)
#A22620
(x3)
#A21660
16a
11
1
E
16b
Markedwithan"R"
Markedwithan"L"
1
1
Proper orientation of CAM LOCK
Tip
Assembly
Quick
LeftCabinetMember
RightCabinetMember
(x1)
#A56750
(black)
#A56770 (linen)
(x6)
#A11080
6
6
6
1
1
