15
amewi.com
To turn right
4. Pull back the throttle trigger of the transmitter and move the steering knob
clockwise.
Pull back
6. If the boat drifts to the right: Press the left rudder trim on the transmitter and
the boat will gradually correct the rudder alignment. It will start moving straight.
7. If the boat drift to the left: Press the right rudder trim on the transmitter and the
boat will gradually correct the rudder alignment. It will start moving straight.
5. If the boat capsizes: Push forward the throttle trigger of the transmitter and then
pull back at once. The boat will then return to normal. (The capsize reset
function will turn off automatically when the boat in low battery.)
Left Rudder trim
Right Rudder trim
