AMGO 408-P - Product Features and Specifications; Model 408-P Features and Specifications

1
I. PRODUCT FEATURES AND SPECIFICATIONS
4-POST MODEL 408-P FEATURES
· Single point manual safety release.
· Four mechanical locking devices, each equipped with both primary
and secondly safety locks.
· Power-side column can be installed at both side, front or rear.
· Non-skid diamond platforms and adjustable safety lock ladders.
· Optional kits: Sliding jack with hand pump, caster kits, Jack tray, plastic oil tray.
MODEL 408-P SPECIFICATIONS
Model
Lifting
Capacity
Lifting
Height
Lifting
Time
Overall Length
(Inc. Ramps)
Overall
Width
Overall
Height
Width
Between
Columns
Motor
408-P
8000lbs
73 3/4
”
1872mm
40S
207”
5257mm
105 1/2”
2680mm
82 7/8”
2105mm
96”
2438mm
110V/1.0HP
220V:2.0HP
Fig. 1
