17
Motor wire (M1
、
M2
、
M3) are connected to the three wires in the motor.
Turn on the power, push button “UP”, if motor run but lift is not worked, pls. change the
wires connection.
3.3 380V Circuit diagram (See Fig. 28).
Circuit diagram component list
4. 220V Wire connection and circuit diagram
Item
Name
Code
Specification
Item
Name
Code
Specification
1
Power Switch
QS
380V AC
7
Power
indicator
R
White（24V）
2
Fuse
FU
1
25A
8
Push Button
Down
Single
3
Fuse
FU
2
3A
9
Motor
M
Three phase
4
AC Contactor
KM
24V AC
10
Transformer
TC
24V AC
5
Hydraulic
Solenoid Valve
C
24V AC
11
Limit Switch
SQ
10A
6
Push Button
UP
Single
Earth wire
M3
M2
M1
Fig. 27
Fig. 28
Three phase
