I. PRODUCT FEATURES AND SPECIFICATIONS
4-POST MODEL A440-HP FEATURES
· Single point manual safety release.
· Four mechanical locking devices, each equipped with both primary
and secondly safety locks.
· Power-side column can be installed at both side, front or rear.
· Non-skid diamond platforms and adjustable safety lock ladders.
· Optional kits: Sliding jack with hand pump, caster kits, Jack tray, Plastic oil tray.
MODEL A440-HP SPECIFICATIONS
Model
Lifting
Capacity
Lifting
Height
Lifting
Time
Overall
Width
Width
Between
Columns
Gross
Weight
Motor
A440-HP
4.0T
2214mm
54S
3102mm
2860mm
992kg
3.0HP
Fig. 1
