AMI Ion Aurora - User Manual

Questions and Answers

E
Evelyn MacdonaldAug 19, 2025
What to do if my AMI Ion Aurora has no power?
- J
  juliepatrickAug 19, 2025
  If your AMI Game Console has no power, here are several things to check: * Ensure the power cord is connected to a working outlet. * Verify the power switch is turned on. * Confirm the power cord is properly connected to the game's power supply. * Check that the power supply's voltage select switch is set to the correct voltage. * Inspect the harness connections to both the on/off switch and the circuit breaker. * Examine the circuit breaker for any signs of being open. * Verify the AC harness connection to the power supply. * Inspect the line cord.
M
Morgan DanielAug 21, 2025
What does 'ERROR READING DRIVE C' mean on my AMI Ion Aurora and how to fix it?
- J
  Jonathan SmithAug 21, 2025
  The message 'ERROR READING DRIVE C' on your AMI Game Console can be caused by a problem with the hard drive, or in some program versions, by a coin jam while the game is turned on. To resolve this: 1. Turn the game off. 2. Locate DS 1, position 8 and turn it on. 3. Turn the power on to the cabinet. This will start the hard drive checksum test, which should take about 20 minutes to complete. 4. If the hard drive passes the test and displays 'CHECKSUM GOOD' and continues to boot up, this indicates a coin jam. 5. If the hard drive fails the test and the game locks up with a 'CHECKSUM ERROR' message, the hard drive will need to be replaced.
M
michaelmurphyAug 23, 2025
What does 'DISK BOOT FAILURE' mean on my AMI Ion Aurora Game Console and how do I fix it?
- J
  Jeffrey LawrenceAug 23, 2025
  The 'DISK BOOT FAILURE' message on your AMI Game Console indicates that the motherboard isn't receiving data from the hard drive, causing it to lock up. To troubleshoot: * Check the IDE ribbon cable connections to both the motherboard and the hard drive. * Verify the power supply to the hard drive, ensuring it has +5 volts, +12 volts, and ground.
K
kevinstoneAug 26, 2025
What to do if my AMI Ion Aurora Game Console displays 'QUANTUM FIREBALL, SMART FAILURE DETECTED, BACK UP HARD DRIVE'?
- D
  Dave FarmerAug 27, 2025
  If your AMI Game Console displays the message 'QUANTUM FIREBALL, SMART FAILURE DETECTED, BACK UP HARD DRIVE', it means the hard drive's self-diagnostics have found an error. The hard drive will need to be replaced.
R
rachelkhanAug 30, 2025
Why does my AMI Ion Aurora Game Console display 'INVALID KEY' when downloading software?
- R
  Robert StoneAug 30, 2025
  The 'INVALID KEY' message on your AMI Game Console during software download can occur if the security key was replaced before the download, preventing the motherboard from booting from the DVD drive. To resolve this, check that the DVD drive is set as master, verify the ribbon cable connections between the DVD drive and the motherboard, or try another DVD drive or disc set.
J
Joseph HallSep 1, 2025
What to do if my AMI Game Console displays 'CRITICAL ERROR ABORT RETRY FAIL' or 'BAD COMMAND OR FILE NAME' error?
- M
  Marco YoungSep 2, 2025
  If your AMI Game Console shows a 'CRITICAL ERROR ABORT RETRY FAIL' or 'BAD COMMAND OR FILE NAME' error, try reloading the program onto the hard drive using a different set of update discs that are compatible with the security key. If the download fails, try using another DVD drive. If the issue persists, you may need to replace the hard drive.
D
Donald HeathSep 4, 2025
How to fix coin jams in my AMI Game Console?
- A
  Alexis AndersonSep 4, 2025
  To address coin jams in your AMI Game Console: * Check the coin mechanism and coin chute for any coins blocking the pathway. * Ensure the coin harness is properly connected between the normally open and common terminals on the coin switch. * Disconnect the bill acceptor and the coin switch one at a time to identify the source of the problem. * Inspect the coin harness for any pinched or damaged wires. * Disconnect the coin harness from J1, J3, J7, and J8 of the I/O board. If the coin jam persists, the I/O board may need repair.
P
Paul RobinsonSep 6, 2025
What to do if my AMI Ion Aurora Game Console will not download disc?
- E
  Eric HensonSep 6, 2025
  If your AMI Game Console won't download a disc, make sure the disc is correctly installed with the logo facing up. Check the disc for scratches or defects. Try using a different DVD drive or another disc. If you're downloading a disc set, ensure each disc is of the same revision.
D
Darren MillerSep 8, 2025
How to fix 'no video' on AMI Ion Aurora?
- R
  Rita ElliottSep 9, 2025
  To troubleshoot a 'no video' issue on your AMI Game Console: * Check the DC harness connection to the motherboard. * Also, check the AC harness connection to the power supply.
K
Kyle SullivanSep 12, 2025
Why does my AMI Ion Aurora Game Console display 'game locks up with invalid key for version PG3002 – V XXXX'?
- J
  Jeremiah PerezSep 12, 2025
  If your AMI Game Console locks up with the message 'invalid key for version PG3002 – V XXXX', check the program number on the security key to ensure it's compatible with the program on the hard drive. Also, inspect the contacts on the security key socket, lifting up on the contact at the bottom to ensure a good connection with the base of the security key. Verify the USB cable connecting the I/O board to the motherboard. You can also try another security key with the same program number or test the security key in another game with the same program version.
