AMI M9 Series - Table of Contents

Doc No. 740124 2
MODEL 9 SERIES WELD HEAD
OPERATION MANUAL
Table of Contents
Chapter Description Page
1.0 Introduction………………..…………………3
2.0 Unpacking……………………………………3
3.0 Cable hook up……………………………… 3
4.0 Water Cooling………………………........... 5
5.0 Rotation (speed) Auto-Calibration……….. 5
5.2 Rotation (speed) Manual Calibration……. 6
6.0 Clamp Insert Installation………………… 7
7.0 Electrode Geometry & Installation…………9
8.0 Shielding Gas……………………………….14
9.0 Return-to-home (rotor) position
adjustment….. ……………………………. .15
10.0 Cleaning & maintenance…………………. 17
11.0 Storage…………………………………….. 18
