Amica EHC Series User Manual

14
INSTALLATION
Installing the hob in worktop opening
● Use four “A” brackets for 38 mm thick worktops. Fit the hob into worktop opening as shown
on gure 2 and 3. To properly secure hob in 28 mm thick worktop, use four 15x15x50 mm
wooden blocks in addition to “A” brackets. Fit the hob into worktop opening as shown on
gure 4 and 5.
● Check if adhesive seal is properly applied to the hob's ange.
● Loosely attach xing brackets to the bottom of the hob
● Remove dust from the worktop, insert hob into the opening and press in rmly,
● Position xing brackets perpendicularly to the hob's edge and tighten rmly.
1 - worktop
2 - screw
3 - xing bracket
4 - hob
5 - seal
54
321
2
3
320
560
490
min
60
min
50
466

Amica EHC Series Specifications

General

Type	Electric
Number of Ovens	1
Hob Type	Ceramic
Number of Burners/Zones	4
Energy Rating	A
Width	60 cm
Oven Type	Multifunction
Colour	Black
Safety Features	Cool Door
