Amica EHC Series User Manual

16
INSTALLATION
Fig. B
Fig. A
Fig. C
Assembly of the oven:
 Make an opening with the dimensions
given in the diagram for the oven to be
tted.(Fig.A)
 Make sure the mains plug is disconnected
and then connect the oven to the mains
supply.
 Partially insert the oven into the prepared
opening and connect the oven to the hob.
(Fig.B)
 The appliance must be earthed. Connect
the earth lead of the hob (yellow–green)
with the earth terminal of the oven
(marked ) which is located near the
connection box
 Insert the oven completely into the open-
ing without allowing the four screws in the
places shown in the diagram to fall out.
(Fig.C)

Amica EHC Series Specifications

General

Type	Electric
Number of Ovens	1
Hob Type	Ceramic
Number of Burners/Zones	4
Energy Rating	A
Width	60 cm
Oven Type	Multifunction
Colour	Black
Safety Features	Cool Door
