ADJUSTING YOUR AMIGO
To adjust your Amigo to a comfortable driving position, you can alter the Handle,
Seat and Armrests as follows:
EZ-Tilt Handle Adjustment
To adjust the angle of the Handle, turn the Adjustment Lever counterclockwise. Move the
Handle to the desired position. Tighten the Adjustment Lever by turning it clockwise (Figure 1).
The placement of the spring-activated Adjustment Lever, itself, can be moved out of the way for
your comfort. Pull the Adjustment Lever straight out. Turn in either direction. Release Adjustment
Lever at desired placement (Figure 2).
DO NOT USE THE HANDLE ADJUSTMENT LEVER FOR A FOOT REST. SUCH USE MAY
CAUSE THE ADJUSTMENT LEVER TO LOOSEN THE HANDLE AND CAUSE PERSONAL INJURY.
Adjusting Seat Height
To raise or lower your seat height, remove the nut and screw that holds the
Seat Collar in place on the Seat Post, then adjust and reinstall in the
desired hole on the Seat Post. (Figure 3)
It is recommended that the Seat Lock be installed in the second hole position
from the seat on a Folding Seat and the Premier I Seat. (Figure 4)
Seat Lock Lever
This allows the Seat to rotate 360 degrees and lock in any position desired. The Seat Lock
Lever is a bar with a vinyl cap on its end, located under the right side of the Seat. Push the
Lever forward to rotate to any position.
Adjustable Armrest Width (Premier I Seat Only)
The Armrest width is determined by loosening the Armrest Knobs and tightening them
when the arms are at the desired width.
Flip Up Armrest (Premier I Seat Only)
By pulling up on the end of either Armrest, the Armrest will flip back
for easy transfer in and out of the Amigo.
6
Figure 1
Figure 2
Figure 3
Figure 4
