Amit RRAM-MCT/E12 Series - Technical Specifications

RRAM-MCT/E12-XX
7/40 rram-mcte12-xx_g_en_100
2. Technical parameters
Number of outputs
2 ×
Number of channels
2 ×
Permanent output sinus power
(THD=1 %) 1)
2 × 30 W
Peak music power output
2 × 48 W
Minimum load impedance
6 Ω / channel
Connection point
WAGO 769-675/003-000
Cable counterpart
WAGO 769-115/021-000
Wire cross section
0.5 mm
2
to 4 mm
2
1
) At 4 Ω load impedance, with power supply voltage VIN = 24 V DC and
ambient temperature +25 °C.
Quantity
2
)
1 ×
Input range
0.707 V
eff
Input impedance
20 kΩ
Connection point
Jack 3.5 mm stereo socket
Quantity
2
)
1 ×
Input range
0.707 V
eff
Input impedance
8.5 kΩ
Connection point 3)
WAGO 769-675/003-000
Cable counterpart
WAGO 769-115/021-000
Wire cross section
0.5 mm
2
to 4 mm
2
Quantity
1 ×
Maximum input voltage
30 V
Maximum input level for Log. 0
7.0 V
Minimal input level for Log. 1
9.2 V
Galvanic isolation
4
)
Yes, 1000 V AC / 1 minute
Connection point
3
)
WAGO 769-675/003-000
Cable counterpart
WAGO 769-115/021-000
Wire cross section
0.5 mm
2
to 4 mm
2
2)
Front and rear audio input share one codec input channel.
3)
Rear audio input and digital input share one connector outlet.
4)
Galvanic isolation must not be used for dangerous voltage isolation.
Quantity
2 ×
Relay type
Switching, SPDT
Isolation strength
5000 V AC
Nominal switched voltage
250 V AC / 24 V DC
Maximum switched current
8 A
Switch-on time
10 ms
Switch-off time
5 ms
Contact lifetime
20 × 106 cycles
Outputs protection
External circuit-breaker
Connection point
WAGO 769-675/003-000
Cable counterpart
WAGO 769-115/021-000
Audio output
Note
Front audio
input
Rear audio
input
Digital input
Note
Relay outputs
