RRAM-MCT/E12-XX
rram-mcte12-xx_g_en_100 8/40
Wire cross section
0.5 mm
2
to 4 mm
2
Number of UIC interfaces
1 ×
UIC functionality
According to UIC 568
Galvanic isolation
No
Connection point
WAGO 769-668/003-000
Cable counterpart
WAGO 769-108/021-000
Wire cross section
0.5 mm
2
to 4 mm
2
Max. number of devices on bus.
20
Cable maximum length
100 cm
Handset fixation
Magnetic holder
Handset detection
Magnetic contact
Button
1 ×
Number of button presses
10
6
Number of lines
1 ×
Data transmission rate
100 Mbps
Galvanic isolation
Yes
Isolation strength 4)
1000 V AC / 1 min
Connection point
M12 connector, socket, 4 pins D code
Recommended cabling
Min. STP CAT5
Maximum segment length
100 m
Nominal power supply voltage
24 V DC
Power supply voltage range
16.8 V to 30 V DC
Power consumption
Max. 6.2 A at 24 V DC
Inrush current
310 A / < 200 µs
Galvanic isolation
No
Connection point
WAGO 769-675/003-000
Cable counterpart
WAGO 769-115/021-000
Wire cross section
0.5 mm
2
to 4 mm
2
Under-foil button
8 ×
Backlight
Yes, adjustable intensity
Number of operations
10
6
Acoustic indication
1 × Internal speaker
Mechanical design
To be built into panel
Surface finish cover, panel
Powder coating
Colour cover
RAL 9005
panel
RAL 9005
foil
RAL 7016
foil print
RAL 9010
Mounting
4 × hole 7 mm
Ingress protection rate –
front panel
back cover
IP40
IP20
Weight – netto
– brutto
2.46 kg ±5 %
2.94 kg ±5 %
Dimensions (w × h × d)
(140 × 330 × 149) mm
Package dimensions (w × h × d)
(160 × 360 × 170) mm
UIC interface
Phone
handset
Ethernet
Power supply
Controls
Mechanics
