RRAM-MCT/E12-XX
9/40 rram-mcte12-xx_g_en_100
Unit overall mass of plastics
Max 463 g
Included mass of self-extinguishing
plastics
Max 463 g
Exchange unit does not contain
PUR, PVC, Asbestos
Exchange meets
2011/65/EU (ROHS)
1907/2006EU (REACH)
Under-foil buttons
10
6
touches
Operating temperature range
-40 °C to 70 °C
Storage temperature range
-40 °C to 70 °C
Maximum ambient humidity
< 95 % non-condensing
Reliability (MTBF) min.
300 000 h, with 45 °C of ambient
temperature
Expected lifetime
15 years
Exchange unit is supplied with loader, which enables software uploading via Ethernet
line by service application provided for free.
Exchange unit is intended to operate up to 1 400 m above the sea level.
Exchange unit is designed to meet the Temperature Class TX.
According to EN 61373 standard, exchange unit is classified in terms of vibrations
into Category 1, Class B (mounting to vehicle body).
Permissible supplying voltage drop-out duration: max 10 ms (Class S2 according to
Chapter 3.1.1.2 of EN 50155:2007 standard).
For supply voltage switching are permissible conditions of C1 and C2 Class.
The device is not classified according to EN 50128:2011 Railway applications –
Communications, signalling and processing systems – Software for railway control
and protection systems.
The device is not classified according to EN 50129:2003 Railway applications –
Communication, signalling and processing systems – Safety related electronic
systems for signalling.
Dangerous
materials
Components
with reduced
lifetime
Temperatures
Others
Software
equipment
Claims of EN
50155:2007
Safety
classification
