50 ASC 70 / 90 / 100 / 110 / 130 / 150 / 200 / 250
5. Description of the machine
Weights
Operational weight of the machine ASC 70 in kg [lb] according to ISO 6016
Machine
ASC 70 D
ASC 70 HD
ASC 70 PD
ASC 70 HDPD
ASC 70 PDB
Cab + ROPS frame 7255 [15.994] 7200 [15.873] 7700 [16.976]
Weight of two tires with liquid lling in kg [lb] 420 [926] 420 [926] 420 [926]
Weight of three pad-foot segments in kg [lb] 1090 [2.403]* - -
Weight cabin kg [lb] 220 [485] 220 [485] 220 [485]
* - Smooth drum can be tted with padfoots segments.
For a machine with roof, deduct the weight of the cab and add 140 kg.
For the mountain version of the machine indicated by HT 480 kg must be added.
The maximum weight of roller 9745 kg (21.484 lb) with smooth drum, padfod segments, tyres lling with water, blade and design
implemetation HT
Operational weight of the machine ASC 90 in kg [lb] according to ISO 6016
Machine
ASC 90 D
ASC 90 HD
ASC 90 PD
ASC 90 HDPD
ASC 90 PDB
Cab + ROPS frame 8935 [19.698] 8880 [19.577] 9380 [20.679]
Weight of two tires with liquid lling in kg [lb] 420 [926] 420 [926] 420 [926]
Weight of three pad-foot segments in kg [lb] 1090 [2.403]* - -
Weight cabin kg [lb] 220 [485] 220 [485] 220 [485]
* - Smooth drum can be tted with padfoots segments.
For a machine with roof, deduct the weight of the cab and add 140 kg.
For the mountain version of the machine indicated by HT 480 kg must be added.
The maximum weight of roller 11425 kg (25.187 lb) with smooth drum, padfod segments, tyres lling with water, blade and design
implemetation HT.
