51ASC 70 / 90 / 100 / 110 / 130 / 150 / 200 / 250
WORKSHOP MANUAL
Operational weight of the machine ASC 110 in kg [lb] according to ISO 6016
Machine ASC 110 D ASC 110 PD ASC 110 PDB
Cab + ROPS frame 11665 [25.716] 12095 [26.664] 13005 [28.670]
Weight of two tires with liquid lling in kg [lb] 1200 [2.645] 1200 [2.645] 1200 [2.645]
Weight of three pad-foot segments in kg [lb] 1680 [3.704]* - -
Weight cabin kg [lb] 220 [485] 220 [485] 220 [485]
* - Smooth drum can be tted with padfoots segments.
For a machine with roof, deduct the weight of the cab and add 140 kg.
For the mountain version of the machine indicated by HT+HD 1 235 kg (2.723 lb) must be added.
The maximum weight of roller 16 600 kg (36.597 lb) with smooth drum, padfod segments, tyres lling with water, blade and design
implemetation HD + HT.
Operational weight of the machine ASC 130 in kg [lb] according to ISO 6016
Machine ASC 130 D ASC 130 PD ASC 130 PDB
Cab + ROPS frame 12800 [28.219] 12900 [28.439] 13550 [29.873]
Weight of two tires with liquid lling in kg [lb] 1200 [2.645] 1200 [2.645] 1200 [2.645]
Weight of three pad-foot segments in kg [lb] 1680 [3.704]* - -
Weight cabin kg [lb] 220 [485] 220 [485] 220 [485]
* - Smooth drum can be tted with padfoots segments.
For a machine with roof, deduct the weight of the cab and add 140 kg.
For the mountain version of the machine indicated by HT+HD 1 235 kg (2.723 lb) must be added.
The maximum weight of roller 17735 kg (39.099 lb) with smooth drum, padfod segments, tyres lling with water, blade and design
implemetation HD, HT.
Operational weight of the machine ASC 100 in kg [lb] according to ISO 6016
Machine ASC 100
Cab + ROPS frame 10200 (22487)
Weight of three pad-foot segments in kg [lb] 1720 (3792)
Weight cabin kg [lb] 220 (485)
For a machine with roof, deduct the weight of the cab and add 140 kg.
The maximum weight of roller 10 120 kg (22.211 lb) with smooth drum, tyres standard lling with water.
