52 ASC 70 / 90 / 100 / 110 / 130 / 150 / 200 / 250
5. Description of the machine
Operational weight of the machine ASC 150 in kg [lb] according to ISO 6016
Machine ASC 150 D ASC 150 PD ASC 150 PDB
Cab + ROPS frame 14550 [32.076] 14460 [31.878] 15280 [33.687]
Weight of two tires with liquid lling in kg [lb] 1200 [2.645] 1200 [2.645] 1200 [2.645]
Weight of three pad-foot segments in kg [lb] 1680 [3.704]* - -
Weight cabin kg [lb] 220 [485] 220 [485] 220 [485]
* - Smooth drum can be tted with padfoots segments.
For a machine with roof, deduct the weight of the cab and add 140 kg.
For the mountain version of the machine indicated by HT+HD 1 235 kg (2.723 lb) must be added.
The maximum weight of roller 19485 kg (42.957 lb) with smooth drum, padfod segments, tyres lling with water, blade and design
implemetation HD, HT.
Operational weight of the machine ASC 200 in kg [lb] according to ISO 6016
Machine ASC 200 D ASC 200 PD ASC 200 PDB
Cab + ROPS frame 20875 [46.020] 20945 [46.175] 22025 [48.556]
Weight of two tires with liquid lling in kg [lb] 1200 [2.646] 1200 [2.646] 1200 [2.646]
Weight of three pad-foot segments in kg [lb] 2625 [5.787]* - -
Weight cabin kg [lb] 220 [485] 220 [485] 220 [485]
* - Smooth drum can be tted with padfoots segments.
For a machine with roof, deduct the weight of the cab and add 140 kg.
For the mountain version of the machine indicated by HT+HD 1 200 kg (2.646 lb) must be added.
The maximum weight of roller 26980 kg (59.481 lb) with smooth drum, padfod segments, tyres lling with water, blade and design
implemetation HD, HT.
