54 ASC 70 / 90 / 100 / 110 / 130 / 150 / 200 / 250
5. Description of the machine
Basic dimensions
Basic dimensions of model ASC 70
ASC 70 D ASC 70 PD ASC 70 PDB
Total length in mm [in] 5195 [204.5] 5195 [204.5] 5555 [218.7]
Total width in mm [in] 1880 [74] 1880 [74] 2215 [87.2]
Height in mm [in] 2870 [113] 2870 [113] 2870 [113]
Outer contour turning radius in mm [in] 4685 [184.4] 4685 [184.4] 5242 [206.3]
Inner turning radius in mm [in] 3090 [122] 3090 [122] 3090 [122]
Dimensions of the tires 14.9-24" 14.9-24" 14.9-24"
Filling pressure in kPa [PSI] 150 [21.7] 150 [21.7] 150 [21.7]
Basic dimensions of model ASC 90
ASC 90 D ASC 90 PD ASC 90 PDB
Total length in mm [in] 5195 [204.5] 5195 [204.5] 5555 [218.7]
Total width in mm [in] 1930 [76] 1930 [76] 2215 [87.2]
Height in mm [in] 2870 [113] 2870 [113] 2870 [113]
Outer contour turning radius in mm [in] 4795 [188.8] 4795 [188.8] 5242 [206.3]
Inner turning radius in mm [in] 3090 [122] 3090 [122] 3090 [122]
Dimensions of the tires 14.9-24" 14.9-24" 14.9-24"
Filling pressure in kPa [PSI] 150 [21.7] 150 [21.7] 150 [21.7]
Basic dimensions of model ASC 100
ASC 100
Total length in mm [in] 5630 [221.7]
Total width in mm [in] 2250 [88.6]
Height in mm [in] 3027 [119.2]
Outer contour turning radius in mm [in] 5575 [219.5]
Inner turning radius in mm [in] 3275 [128.9]
Dimensions of the tires 23.1 - 26"
Filling pressure in kPa [PSI] 160 [23.2]
Basic dimensions of model ASC 110
ASC 110 D ASC 110 PD ASC 110 PDB
Total length in mm [in] 5686 [223.8] 5686 [223.8] 6094 [240]
Total width in mm [in] 2436 [95.9] 2436 [95.9] 2950 [116.1]
Height in mm [in] 3150 [124] 3150 [124] 3150 [124]
Outer contour turning radius in mm [in] 5370 [211.4] 5370 [211.4] 5738 [225.9]
Inner turning radius in mm [in] 3050 [120] 3050 [120] 3050 [120]
Dimensions of the tires 23.1 - 26" 23.1 - 26" 23.1 - 26"
Filling pressure in kPa [PSI] 160 [23.2] 160 [23.2] 160 [23.2]
