55ASC 70 / 90 / 100 / 110 / 130 / 150 / 200 / 250
WORKSHOP MANUAL
Basic dimensions of model ASC 130
ASC 130 D ASC 130 PD ASC 130 PDB
Total length in mm [in] 5686 [223.8] 5686 [223.8] 6094 [240]
Total width in mm [in] 2500 [98.4] 2500 [98.4] 2950 [116.1]
Height in mm [in] 3150 [124] 3150 [124] 3150 [124]
Outer contour turning radius in mm [in] 5395 [212.4] 5395 [212.4] 5738 [225.9]
Inner turning radius in mm [in] 3050 [120] 3050 [120] 3050 [120]
Dimensions of the tires 23.1 - 26" 23.1 - 26" 23.1 - 26"
Filling pressure in kPa [PSI] 160 [23.2] 160 [23.2] 160 [23.2]
Basic dimensions of model ASC 150
ASC 150 D ASC 150 PD ASC 150 PDB
Total length in mm [in] 5686 [223.8] 5686 [223.8] 6094 [240]
Total width in mm [in] 2500 [98.4] 2500 [98.4] 2950 [116.1]
Height in mm [in] 3150 [124] 3150 [124] 3150 [124]
Outer contour turning radius in mm [in] 5395 [212.4] 5395 [212.4] 5738 [225.9]
Inner turning radius in mm [in] 3050 [120] 3050 [120] 3050 [120]
Dimensions of the tires 23.1 - 26" 23.1 - 26" 23.1 - 26"
Filling pressure in kPa [PSI] 160 [23.2] 160 [23.2] 160 [23.2]
Basic dimensions of model ASC 200
ASC 200 D ASC 200 PD ASC 200 PDB
Total length in mm [in] 6300 [248] 6300 [248] 6790 [267]
Total width in mm [in] 2500 [98.4] 2500 [98.4] 3000 [118.1]
Height in mm [in] 3265 [128.5] 3265 [128.5] 3265 [128.5]
Outer contour turning radius in mm [in] 6280 [247.2] 6280 [247.2] 6615 [260]
Inner turning radius in mm [in] 3900 [153.5] 3900 [153.5] 3900 [153.5]
Dimensions of the tires 23.5 - 25" 23.5 - 25" 23.5 - 25"
Filling pressure in kPa [PSI] 150 [22] 150 [22] 150 [22]
Basic dimensions of model ASC 250
ASC 250 D ASC 250 PD ASC 250 PDB
Total length in mm [in] 6560 [258.2] 6560 [258.2] 6990 [275.2]
Total width in mm [in] 2500 [98.4] 2500 [98.4] 3000 [118.1]
Height in mm [in] 3265 [128.5] 3265 [128.5] 3265 [128.5]
Outer contour turning radius in mm [in] 6315 [248.6] 6315 [248.6] 6820 [268.5]
Inner turning radius in mm [in] 3950 [155] 3950 [155] 3950 [155]
Dimensions of the tires 23.5 - 25" 23.5 - 25" 23.5 - 25"
Filling pressure in kPa [PSI] 150 [21.7] 150 [21.7] 150 [21.7]
