21 - HYDRAULIC
Legend:
1 - Pump of travel
*2 - Pump of vibration
**2 - Pump of vibration
*3 - Hydromotor of the drum drive
**3 - Hydromotor of the drum drive
*4 - Hydromotor of vibration
**4 - Hydromotor of vibration
5 - Hydromotor of the wheels drive
8 - Pump of steering
9 - Power steering unit
10 - Valve ASC
11 - Hydraulic cylinders of steering
13 - Pressure switch
14 - Suction basket
15 - Block of filtration
16 - Filling socket
17 - Oil level gauge
18 - Cooler combined
19 - Non-return valve
20 - Thermoregulator
21 - Measuring quickcoupler
22 - Filling quickcoupler
23 - Quickcoupler
24 - Quickcoupler
25 - Thermometer sensor
26 - Aggregate
27 - Manual pump
28 - Lifting block
29 - Hydraulic lock
30 - Hydraulic motor for lifting the cabin
31 - Hydraulic motor for lifting the hood
* - ASC 110
** - ASC 150
HYDRAULIC CIRCUIT CONNECTIONS IN ASC 110
AND ASC 150 - 4 VALVES ASC
The connections of hydraulic circuit are identical in both
machine types. The only difference is in the type of pumps and
hydraulic motors.
Machine ASC 110 uses vibration pump 90R042 and vibration
hydraulic motor 90M042
Machine ASC 150 uses vibration pump 90R055 and vibration
hydraulic motor 90M055
Moreover, it differs in the set-up of the over-flow valve that
controls pressure in the body of the vibration pump, where in
ASC 110 pressure has been set to 42 bar, and in ASC 150 to
28 bar. The control pressure in the bodies of travel pumps has
been set in both cases to 22 bars.
