Trans la ti on of the Ori gi nal
ope ra ting in struc tions (EN)
Book ID: 2-00013021
ATR 60 P
ATR 68 P
Serial Nr. ########-
Honda GXR120RT
Serial Nr. ########-

Table of Contents

Other manuals for Ammann ATR 60 P

Preview: Operator's Manual
Operator's Manual154 pages

Questions and Answers

  • P
    petersantosAug 4, 2025
    Why Ammann ATR 60 P engine does not start?
    • C
      craig16Aug 4, 2025
      There are several reasons why the engine might not start. It could be due to a closed fuel valve – ensure it is set to the «ON» position. Another reason could be an empty fuel tank – refill it. A faulty ignition spark could also be the culprit – replace the spark plug. Check that the ignition switch is set to «ON», and if it’s faulty, replace it. Finally, verify the engine oil level, as a low level can prevent the engine from starting.
  • S
    Stephanie MeyersAug 9, 2025
    What to do if Ammann ATR 60 P engine does not reach top speed?
    • A
      Antonio GonzalezAug 10, 2025
      If the engine isn't reaching its top speed, consider these possible causes: the throttle cable might be faulty and need replacement, or the gas cable adjustment may be incorrect, requiring adjustment. Also, a clogged air filter can restrict performance, so clean the filter cartridge or replace it. In some cases, the engine or carburetor itself may be faulty, necessitating replacement or repair.
  • J
    Juan KingAug 14, 2025
    What to do if Ammann Construction Equipment engine does not start when starter is operated?
    • C
      cynthia32Aug 14, 2025
      If the engine fails to start when the starter is engaged, the starter itself may be faulty and require replacement. Alternatively, a broken spring within the starter mechanism could be the cause, also necessitating starter replacement.
  • E
    Elizabeth LandryAug 19, 2025
    Why Ammann Construction Equipment tamper movement is irregular, jumps?
    • H
      Harold SteinAug 20, 2025
      Irregular or jumping tamper movement can stem from a few issues. The speed might be incorrect, so correct it. The springs could be broken and need to be renewed by Ammann Customer Service. Also, ensure the throttle lever is set to «max».
  • C
    Crystal HarmonAug 25, 2025
    What to do if Ammann ATR 60 P engine runs at high speed, but no vibration?
    • J
      John ValentineAug 25, 2025
      If the engine runs at high speed without producing vibration, the centrifugal clutch may be faulty and require replacement. Alternatively, the connecting rod might be broken, requiring renewal by the Ammann after-sales service.
  • C
    Christopher CookAug 29, 2025
    How to fix Ammann Construction Equipment starter cable if reversing starter does not return to initial position?
    • K
      Kimberly TerryAug 29, 2025
      If the reversing starter cable doesn't return to its initial position, it could be due to fouling, in which case cleaning the starter is recommended. Alternatively, a broken spring might be the cause, requiring replacement of the starter.

Summary

Foreword

Manual Contents and Purpose

Overview of the manual's sections and its aim to simplify operation and avoid malfunctions.

Safety Regulations

Intended Use and Misuse Hazards

Defines correct usage and potential dangers from misuse or untrained operation.

Operator Qualifications and Responsibilities

Specifies requirements for machine operators, including age and training.

Machine Modifications and Unauthorized Parts

Prohibits unauthorized changes and warns against using non-original parts.

Loading, Starting, and Safe Operation Procedures

Guidelines for loading, starting, operating in confined spaces, and general operation.

Parking and Securing the Machine

Instructions for safely parking and securing the tamper.

Refueling and Maintenance Safety

Safety guidelines for refueling, maintenance, and working on the fuel system.

Engine and Tamping Plate Safety Precautions

Specific safety points for working on the engine and tamping plate.

Cleaning and Repair Safety Guidelines

Safe methods for cleaning the machine and requirements for repairs.

Testing Requirements and Machine Disposal

Outlines testing needs and environmentally sound disposal practices.

Technical Data

Machine Dimensions and Weights

Provides physical dimensions and weight specifications for the machine.

Drive System and Performance Specifications

Details engine, power, speed, fuel consumption, and performance data.

Optional Equipment and Noise;Vibration Data

Lists optional equipment and presents measured noise levels and vibration values.

Operation

Machine Description and Component Overview

General description of the tamper and an overview of its main components.

Pre-Operation Checks and Safety

Essential checks and safety precautions before starting the machine.

Motor Operation and Control Functions

Details motor operation, including low oil protection and accelerator cable functions.

Safe Motor Starting Procedures

Step-by-step guide on how to safely start the motor, including choke and accelerator usage.

Post-Start Warm-up and Shutting Down

Instructions for warming up the motor and safely shutting it down.

Adjusting Working Height and Advance Rate

How to adjust the guide bar for working height and control the machine's forward speed.

Operating the Tamper Effectively

Guidance on operator position and throttle settings for effective tamping.

Operating Hour Indicator Functionality

Explains the optional operating hour indicator and its display features.

Transport

General Loading and Transport Safety

Safety warnings and procedures for transporting and loading the machine.

Short Distance Transport and Securing

Guidelines for transport over short distances and securing the machine for transit.

Maintenance

General Maintenance Information and Precautions

Emphasizes careful maintenance for longevity and lists general precautions.

Scheduled Maintenance Tasks and Intervals

Outlines a schedule for regular maintenance checks and replacements.

Lubrication Schedules and Alternative Lubricants

Specifies motor and tamping system oil, and lists alternative lubricants.

Maintenance Motor

Fuel System Safety and Fuel Quality

Critical safety rules for refueling and specifications for acceptable fuel quality.

Refueling and Fuel Filter Maintenance

Step-by-step instructions for refueling and cleaning/replacing the fuel filter.

Checking Motor Oil Level

Detailed steps on how to check the engine oil level correctly.

Air Filter Maintenance Procedures

Instructions for cleaning or replacing the air filter element.

Safety Air Filter and Pre-Separator Maintenance

Maintenance for safety air filter and information on the optional pre-separator.

Maintenance Machine

General Machine Cleaning and Checks

Daily cleaning tasks and checks for damage to cables, hoses, and connections.

Screw Connection Checks and Tightening Torques

Importance of checking connections and recommended torques for screws.

Padfoot Oil Level Check and Oil Change

Procedures for checking and changing the oil in the padfoot system.

Retrofit

Padfoot Shortener and Extension Installation

Instructions for replacing the padfoot adaptor to install shorteners or extensions.

Troubleshooting

General Troubleshooting Information and Safety

Safety rules and general advice for troubleshooting and repairs.

Common Faults and Recommended Solutions

A table listing common faults, their possible causes, and recommended solutions.

Storage

Preparation for Extended Storage

Guidelines for preparing the machine for long-term storage, including environment and cleaning.

Return to Service Procedures After Storage

Steps to follow before resuming operation after storage.
