A M P R E S E A R C H P O W E R S T E P
T M
– F O R D S u p e r D u t y
1
x2
Running board assembly
D
B
(A) End cap left (x1)
(B) End cap right (x1)
(C) T-nut insert (x2)
(D) Socket cap screw (x2)
(E) End cap wedge right (x1)
(F) End cap wedge left (x1)
A
C
E
F
Cut Dimension
2
Motor Linkage assembly
5
Wire harness
3
Idler Linkage assembly
x2
x2
6
A06 Controller
7
Posi-Tap™
x4
8
x18
M8 Hex Bolt w
Conical washer
4
Rail Assembly
9
x10
M10 Button Head
bolt
