2
Index
1. GENERAL INFORMATION 3
1.1 PRODUCER 3
1.2 WARRANTY 3
1.3 PRE-ARRANGEMENTS CHARGED TO THE
CUSTOMER 3
2. MACHINE DESCRIPTION 4
2.1 WORKING PRINCIPLE 4
2.2 MAIN COMPONENTS 4
2.3 MACHINE STRUCTURE 4
2.4 DIMENSIONS 5
2.5 TECHNICAL DATA 5
2.6 TOOLS 5
2.7 EQUIPMENT 5
2.7.1 Standard 5
2.7.2 Optionals on request 5
3.SAFETY 6
3.1 SCHEDULED USE 6
3.2 INADVISABLE USE 6
3.3 PROTECTION DEVICES 6
3.4 STOP FUNCTIONS 6
3.5 SAFE WORKING PROCEDURES 6
4. INSTALLATION 7
4.1 SHIPPING AND HANDLING 7
4.2 STORAGE 7
4.3 PRELIMINARY ARRANGEMENTS 8
4.4 ASSEMBLY 9
4.5 POSITIONING 9
4.6 CONNECTIONS 10
4.6.1 Pneumatic connection 10
4.6.2 Electric connection 11
4.7 PRELIMINARY CONTROLS 12
4.8 ADJUSTMENTS 12
4.8.1 Vertical clamp adjustment 13
4.8.3 Measurement adjustment 13
4.8.4.1 Cutting angle adjustment 13
4.8.4.2 Blade positioning 14
4.8.4.3 Adjustment of blades vertical angle (see the figure
4.8.4 B) 14
4.8.4.4 Blade replacement 16
4.9 IDLE TESTING 16
5. WORKING 17
5.1 CONTROL PANEL 17
5.2 MACHINE’S COMMISSIONING 18
5.3 WAYS OF WORKING 19
5.4 NORMAL STOP 19
5.5 EMERGENCY STOP 19
5.6 RESTORATION 19
5.7 PUTTING OUT OF COMMISSIONING 19
6 MAINTENANCE 20
6.1 STATE OF MAINTENANCE 20
6.2 MACHINE’S ISOLATION 20
6.3 PARTICULAR CAUTIONS 20
6.4 CLEANING 20
6.5 LUBRICATION 20
6.6 ORDINARY MAINTENANCE 20
6.7 EXTRAORDINARY MAINTENANCE 21
7. DIAGNOSTICS 22
7.1 SAFETY ADVICE 22
7.2 FAILURE’S SEARCH 22
7.3 REQUEST FOR ASSISTANCE 23
8. SPARE PARTS 23
8.1 SPARE PARTS LIST 23
8.2 SPARE PARTS ORDERING 23
9.ATTACHMENTS 24
9.1 DECLARATIONS 24
9.2 SCHEMES 24
