Maintenance
SCADA* - These registers/bits must be monitored and included in the trip permissives for all safety
system applications when this protocol is selected.
Register
Description
R/W
Detail
Format
SCADA*
32
Last Min Value permyriad.
May be written with 0 to
reset.
R/W
Write 0 to this register to
reset the Last Peak
Values (LPVs)
Signed Int
33
Last Min Value time and
date
R
Time in seconds since
01-01-2000 00:00
32bit
Unsigned Int
34
Last Min Value time and
date
R
35
Last Max Value permyriad.
May be written with 0 to
reset.
R/W
Write 0 to this register to
reset the Last Peak
Values (LPVs)
Signed Int
36
Last Max Value time and
date
R
Time in seconds since
01-01-2000 00:00
32bit
Unsigned Int
37
Last Max Value time and
date
R
38
Last linearity test checkpoint
1 target permyriad
R
Signed Int
39
Last linearity test checkpoint
1 result permyriad
R
Signed Int
40
Last linearity test checkpoint
2 target permyriad
R
Signed Int
41
Last linearity test checkpoint
2 result permyriad
R
Signed Int
42
Last linearity test checkpoint
3 target permyriad
R
Signed Int
43
Last linearity test checkpoint
3 result permyriad
R
Signed Int
44
Last linearity test checkpoint
4 target permyriad
R
Signed Int
45
Last linearity test checkpoint
4 result permyriad
R
Signed Int
46
Last linearity test checkpoint
5 target permyriad
R
Signed Int
47
Last linearity test checkpoint
5 result permyriad
R
Signed Int
48
Last linearity test checkpoint
6 target permyriad
R
Signed Int
49
Last linearity test checkpoint
6 result permyriad
R
Signed Int
50
Last linearity test number of
test points
R
Signed Int
51
RESERVED
52
Detector Last linearity test
Date (in Ampcontrol date
format)
Time in seconds since
01-01-2000 00:00
32 bit
Unsigned Int
53
Detector Last linearity test
Date
