Amperes MC2106 - Application Example

Note :
1. Paging microphone shall be without zone selection.
2. Speaker output connected to speakers with matching transformer (100V line out ) or without transformer
of 4 Ohm. Total output shall not exceed the specified rating.
8 Ohm Speakers or
100v Speaker with
Matching Trans
Paging
Mic
Dynamic / Cond.
Microphone
stereo
CD1001
Application Example
Page 4
MC2000 Series | Basic Mixer Amplifier
