1. Power unit on with rocker switch.
2. The WIRELESS RECEIVER has its own POWER / VOLUME
Control. Turn Receiver Power On. A Frequency Channel will
appear in the Channel Display. Press UP/DOWN Buttons to
select a channel. Channel number must match channel num-
ber on wireless transmitter.
3. Wireless Microphone/Bodypack Transmitter– set the
transmitter channel selector switch to the same number that
is displayed on the receiver. Select channels 1-16. Install 2 -
“AA” batteries into battery compartment of wireless micro-
phone transmitter or install 1 - “AA” battery into battery com-
partment of wireless bodypack transmitter.
4. MAIN BATTERY STATUS indicator - Red = no battery
power, If four LED’s are glowing, means fully
charged. Charge batteries overnight for best results.
If you need further assistance, please call
1-800-267-5486, 8am-6pm M-F CST .
Getting Started/Quick Setup
SW800 SPECIFICATIONS
Rated Power Output: 100 Watts RMS
Speaker : 8" Bass
4" Tweeter
Frequency Response: 40Hz to 20Khz
Sensitivity: 96dB
Tone Controls: Separate Bass and Treble
Wireless Range: Up to 300 Feet
Wireless Frequency: UHF 584 - 608 MHz
Bluetooth: A2DP Version 3.0
Microphone Input: XLR /1/4" combo connector
Wired Microphone: AmpliVox or other compatible brands
Battery: (2) 12 volt rechargeable SLA, 5 AH,
User accessible and replaceable
AC Power Input: 120 V / 60 Hz
Weight: 33 lbs.
Dimensions (HWD ): 18.5" H x 13.5" W x 12" D
Extension Handle: 21", Locking
Speaker Mount: 1 3/8" pole mount receptacle
Warranty: 1 year Limited Warranty;
Remote Control, Wireless
Microphones, Wireless Receiver,
Bluetooth Module, CD / Media
Player, Rechargeable SLA Batteries.
PLEASE NOTE: THE REMOTE DOES NOT
TURN THE UNIT ON OR OFF. YOU MUST
DO THAT ON THE CONTROL PANEL
