16mm PRECISION PROJECTOR
STORAGE
1. If projector is to be used again in the same location within a few hours all that is
necessary is to turn off all switches, disconnect the line cord, and fold back the reel
arms. It is advisable to roll up the line cord and speaker cable to prevent anyone from
tripping over them.
2. If the projector is to be moved or put away disconnect the line cord, fold back the
upper and lower reel arms, remove the phone plug from the speaker jack and wind
the speaker cable on the reel (5 Fig. 1) as indicated.
3. Place the reel of speaker cable on the screw post inside the speaker enclosure. Place
the speaker enclosure over the projector, making sure that the catches are properly
aligned and close the catches.
4. Store the projector in a dry place and if the location is dusty either use a case slip
cover or wrap the case in tightly woven cloth or canvas to keep the dust from
filtering into the unit.
MAINTENANCE
1. CLEANING
a. Before each show, lift the gate lever (10 Fig. 1) in order to open the gate, then
pullout the pressure shoe carrier (1 Fig. 6). Clean the pressure shoe and aperture
plate, using either the cleaning brush or a soft cloth.
b. Wipe the upper and lower guideways with a soft cloth.
c. Loosen the lens lock screw (9 Fig. 4) and remove the lens (10 Fig. 4). Clean the lens
elements with lens tissue. If the elements cannot be cleaned by breathing on them
and wiping them with tissue, then dampen the tissue with lens cleaner.
WARNING: DO NOT POUR LENS CLEANER OR OTHER SOLVENTS ON
THE LENS ELEMENTS. SOME LIQUIDS MAY CAUSE
SEPARATION OF THE LENS ELEMENTS.
d. Wipe the guide rollers and tension rollers with a soft cloth.
e. Wipe off any dirt on the projector mechanism and periodically clean the case.
2. LUBRICATION
a. After each 25 hours of operation apply 2 or 3 drops of Amproil to the central oil well
(2 Fig. 6). Remove the three cover screws (5 Fig. 2) and pull off the front cover
assembly. Apply 2 or 3 drops of Amproil to the vertical cam shaft bearing oilhole (3
Fig. 6). Before replacing the front cover clean the condensing lenses and reflector.
