Amprobe TIC 300 PRO - LOW Voltage; HIGH Voltage

10
11
Electrical:
Sensitivity: typical as listed on the table below
LOW Voltage
Voltage
(Phase to Ground)
Detection Range
Average
30V 2.7”
75V 9.7”
100V 1’ 1”
120V 1’ 6”
220V 2’ 4”
500V 4’ 2”
1000V 6’ 3”
1500V 7’ 9”
HIGH Voltage
Voltage
(Phase to Ground)
Detection Range
Average
1.5 kV 1’ 2”
2.0 kV 2’ 5”
4.0 kV 3”
10.0 kV 6’ 3”
25.0 kV 9’ 4”
50.0 kV 13’ 0”
75.0 kV 14’ 8”
100.0 kV 19’ 8”
122.0 kV 22’ 0”
