Title: 1073/1084 Horizontal Rack Schedule Nr: AM5028
3 August, 2004 Page:
3
Issue: 1
CABLE FROM:- ROUTING TO:-
Code Type Colour Pin Connector Location Signal Length Comment Pin Connector Location
310-183 24/0.2 Green/Yellow E 330-071 IEC Stud 330-454 Safety Earth
310-183 24/0.2 Green/Yellow 330-069 Chassis Stud 330-454 Safety Earth
310-047 16/0.2 Brown L 330-071 IEC Sleeve with 1A 330-071 Switch
310-052 16/0.2 Blue N 330-071 IEC WA12005 2A 330-071 Switch
Yellow TF14021 1 CN20013 Switch
Yellow TF14021 Centre Solder TF19201
310-052 16/0.2 Blue 1(1of2) Solder TF19201 2 330-071 Switch
Black TF14021 1(2of2) Solder TF19201
Brown TF14021 3 Solder TF19201
Green TF14021 2 Solder TF19201
Blue TF14021 4(1of3) Solder TF19201
310-046 16/0.2 Black 4(2of3) Solder TF19201 4(2of3) Solder TF19201
Red TF14021 4(3of3) Solder TF19201
Orange TF14021 6 Solder TF19201
Violet TF14021 5 Solder TF19201
Grey TF14021 7 Solder TF19201
White TF14021 3 J1 (25VAC) SZN825A084
White TF14021 4 J1 (25VAC)
310-052 16/0.2 Blue 2 SZN825A084 Bolt 330-069 Chassis
310-031 7/0.2 Orange 1 420-691 Housing CN2 2+3 solder via 6K8 Res’s Mic In Ch1 XLR
310-031 7/0.2 Orange 9 420-612 Contacts SYN824B12
8
2+3 solder via 6K8 Res’s Mic In Ch2 XLR
To Next Page
