Document Part No. 4305149, Revision C 18 Sept. 2000
A function is set in the following standard format:
C - # - (2 Digit Function Code) - # - (Master User Code) - # - (Function Setting) - #
↑SGCT ↑SGCT ↑SGCT ↑LGCT
After each “#”, a Short Good Combo Tone (SGCT) will be given, until the last “#” of the sequence is
pressed, at which time it gives a Long Good Combo Tone (LGCT) indicating the successful setting
of a function. Any time during the sequence, if incorrect numbers are pressed, a Bad Combo Tone
(4 short beeps) will sound and the lock will go to rest. A function that has an on/off condition rather
than a numeric setting requires a 1 (on) or a 0 (off) as the Function Setting.
Note: If a default setting is what is desired, then the setting of that function is not necessary.
5.1 Time Delay Settings (Functions 01, 02 & 03)
5.1.1 To Enable Time Delay:
C - # - 01 - # - (Master Code) - # - 1 - #
5.1.2 To Disable Time Delay:
C - # - 01 - # - (Master Code) - # - 0 - #
5.1.3 To set the Delay Period:
C - # - 02 - # - (Master Code) - # - (Delay Period, 1-99 minutes) - #
5.1.4 To set the Open Period:
C - # - 03 - # - (Master Code) - # - (Open Period, 1-9 minutes) - #
Time Delay Setting Example. To set Time Delay for 12 minutes, Open Period to 4 minutes and
the Master Combo is 159260, you must execute 3 function codes as follows:
1. First, Enable the Time Delay with C-#-01-#-159260-#-1-#
2. Then, set the Delay Period with C-#-02-#-159260-#-12-#
3. And finally set the Open Period with C-#-03-#-159260-#-4-#
5.2 Multiple User Settings (Functions 10, 11, 12 & 13)
5.2.1 To Enable Multiple User Mode:
C - # - 10 - # - (Master Code) - # - 1 - #
5.2.2 To Disable Multiple User Mode:
C - # - 10 - # - (Master Code) - # - 0 - #
5.2.3 To Add or Enable a Subordinate User:
C - # - 11 - # - (Master Code) - # - (User Number, 1-8) - #
5.2.4 To Disable a Subordinate User:
C - # - 12 - # - (Master Code) - # - (User Number, 1-8) - #
5.2.5 To Disable all Subordinate Users (1-8):
C - # - 13 - # - (Master Code) - # - 1 - #
Note: Disabling a Subordinate User does not erase the combo associated to that user, so if you
re-enable that User number it is not necessary to re-enter a combo for it unless you are
treating it as a new user.
Enabling Multi-User Mode and Adding a New User Example. To add a User 3 and set a
combination for that User, the Master Combo is 159260 and set User 3 combo to 121314:
1. First, Enable Multiple User Mode with C-#-10-#-159260-#-1-#
2. Then, Add User 3 with C-#-11-#-159260-#-3-#
3. And finally set a combo for User 3 C-#-3-#-159260-#-121314-#-121314-#
5.3 Duress Alarm (Function 20)
5.3.1 To Enable Duress Mode:
C - # - 20 - # - (Master Code) - # - 1 - #
5.3.2 To Disable Duress Mode:
C - # - 20 - # - (Master Code) - # - 0 - #
5.4 Dual Combo (Functions 30 & 31)
5.4.1 To Enable Dual Combo Mode:
C - # - 30 - # - (Master Code) - # - 1 - #
Note: Enabling Dual Combo Mode turns on (enables) User 1 if a User 1 is not already active in
Multi-User mode. The User 1 combo must be set before this feature will function. See
Section 4 for changing instructions.
5.4.2 To Disable Dual Combo Mode:
C - # - 30 - # - (Master Code) - # - 0 - #
5.4.3 To Enable 2 Subordinate User Opening in Dual Combo Mode:
C - # - 31 - # - (Master Code) - # - 1 - #
5.4.4 To Disable 2 Subordinate User Opening in Dual Combo Mode:
C - # - 31 - # - (Master Code) - # - 0 - #
5.5 Armored Car TDL Bypass (Functions 40 & 41)
5.5.1 To Enable Armored Car TDL Bypass:
C - # - 40 - # - (Master Code) - # - 1 - #
Note: Enabling Armored Car Bypass turns on (enables) User 9, which is the Armored Car User.
The User 9 combo must be set before this feature will function. See Section 4 for
changing instructions.
