Initial APWeb Setup by Network Admin
3
APWeb Instruction Manual
Overview of the Admin Home Page
APWeb’s Admin Home page has links for complete site access, while the links on the user’s Home page
are limited to control access. The Admin Home page displays information on the system’s virtual
matrices (VMs) and the number of currently defined macros. It also displays information regarding the
discovery of hardware devices and channel names during bootup if these features are enabled.
The links on the left side of the Home page access the pages listed below:
FIG. 1 Admin Home page
Link Page Function
Home Home The main page in the APWeb site
Controller XBar Controller The controller interface for executing and disconnecting switches
(page 17) and adjusting audio (page 18)
Execute Macro Execute Macro For executing macros (page 20)
Create Macro Create/Edit Macro For creating or deleting macros (page 12)
Define VM Define VM (Manual
Configuration)
For manually defining and deleting virtual matrices (page 13)
Configuration APWeb Configuration For specifying site settings, such as the IP address (page 4) and the
site name (page 8), and for enabling features
Diagnostics Diagnostics For sending a test BCS command (page 7) or launching a Telnet
session to enter BCS commands (page 16)
Administration APWeb Administration For accessing Account Profile (user names and passwords) and Site
Security information (page 5); it also includes the enable/disable
services preferences (page 8)
Contact Info Contact Information Displays the AMX address, phone and fax numbers, and website link
Click logo for AMX Website
APWeb version number
Number of defined macros
Current virtual matrix configurations
Links
Customizable site name
Bootup discovery information
(must be enabled)
To Next Page
