Integrated Master – NetLinx® Programming
204
Hardware Reference Manual – Enova DGX 100 Series Digital Media Switchers
AUDIN_STEREO
Enables or disables the stereo
setting on the audio input port
addressed by the D:P:S.
NOTE: If enabled, the stereo setting is on. If disabled, the stereo setting is off, which means it is
mono.
Syntax:
SEND_COMMAND <DEV>, "'AUDIN_STEREO-<setting>'"
Variable:
setting = stereo setting, either ENABLE or DISABLE
Example:
SEND_COMMAND AUDIO_INPUT_1, "'AUDIN_STEREO-ENABLE'"
Audio Output SEND_COMMANDs
Command Description
?AUDOUT_BALANCE
Requests the current balance
setting for the audio port
addressed by the D:P:S.
Syntax:
SEND_COMMAND <DEV>, "'?AUDOUT_BALANCE'"
Example:
SEND_COMMAND AUDIO_OUTPUT_1, "'?AUDOUT_BALANCE'"
Returns a COMMAND string of the form: AUDOUT_BALANCE-<balance>
NOTE: See the AUDOUT_BALANCE command for the balance range.
AUDOUT_BALANCE
Sets the left and right balance
for the audio port addressed by
the D:P:S.
Syntax:
SEND_COMMAND <DEV>, "'AUDOUT_BALANCE-<balance>'"
Variable:
balance = -20 to +20 steps, left to right (default value is 0).
Example:
SEND_COMMAND AUDIO_OUTPUT_1, "'AUDOUT_BALANCE-5'"
Sets balance to favor the right speaker for audio output port #1 to 5 steps (+).
SEND_COMMAND AUDIO_OUTPUT_1, "'AUDOUT_BALANCE--5'"
Sets balance to favor the left speaker for audio output port #1 to 5 steps (-).
?AUDOUT_DELAY
Requests the delay for the audio
port addressed by the D:P:S.
Syntax:
SEND_COMMAND <DEV>, "'?AUDOUT_DELAY'"
Example:
SEND_COMMAND AUDIO_OUTPUT_1, "'?AUDOUT_DELAY'"
Returns a COMMAND string of the form: AUDOUT_DELAY-<delay>
NOTE: See the AUDOUT_DELAY command for the delay range.
AUDOUT_DELAY
Sets the delay for the audio port
addressed by the D:P:S.
Syntax:
SEND_COMMAND <DEV>, "'AUDOUT_DELAY-<delay>'"
Variable:
delay = 0 to 200 (in ms)
Example:
SEND_COMMAND AUDIO_OUTPUT_1, "'AUDOUT_DELAY-50'"
Sets the delay for the audio output port to 50 milliseconds.
?AUDOUT_EQ_CF
Requests the center frequency
on the specified equalizer band
on the audio output port
addressed by the D:P:S.
Syntax:
SEND_COMMAND <DEV>, "'?AUDOUT_EQ_CF-<band>'"
Example:
SEND_COMMAND AUDIO_OUTPUT_1, "'?AUDOUT_EQ_CF-1'"
Returns a COMMAND string of the form: AUDOUT_EQ_CF-<band>,<value>
NOTE: See the AUDOUT_EQ_CF command for the band and value ranges.
AUDOUT_EQ_CF
Sets the center frequency on the
specified equalizer band on the
audio output port addressed by
the D:P:S.
Syntax:
SEND_COMMAND <DEV>, "'AUDOUT_EQ_CF-<band>,<value>'"
Variables:
band = 1 to 10
value = 20 to 20000 (in Hz)
Example:
SEND_COMMAND AUDIO_OUTPUT_1, "'AUDOUT_EQ_CF-1=80'"
Sets the center frequency on band #1 of audio port 1 equalizer to 80.
SEND_COMMAND AUDIO_OUTPUT_2, "'AUDOUT_EQ_CF-5=100'"
Sets the center frequency on band #5 of audio port 2 equalizer to 100.
