Enova DGX HDMI Boards
68
Hardware Reference Manual – Enova DGX 100 Series Digital Media Switchers
4K HDMI Board EDID Resolutions Supported through Local DDC
NOTE: This section covers all of the default EDIDs for 4K HDMI Boards. In the System Configuration interface, the EDIDs contained in
this section's tables are displayed in a single dropdown menu (General section, Preferred EDID menu) and VICs are differentiated by
the presence of a “p” or “I” in the format. EDID information for HDMI Input and Output Boards is located on the previous page.
4K HDMI DTD (Detailed Timing Descriptor)
* This is the preferred DTD identified in the EDID.
4K HDMI Standard Timings
4K HDMI Established Timings
Resolution Refresh Rate Max. Video Standard
3840x2160p* 30 Hz CTA (VIC 95)
1920x1080p 60 Hz CTA (VIC 16)
1920x1080p 50 Hz CTA (VIC 31)
1920x1200 50 Hz CVR
1920x1200 60 Hz CVR
Resolution Refresh Rate Max.
1920x1200 60 Hz
1680x1050 60 Hz
1600x1200 60 Hz
1440x900 60 Hz
1360x765 60 Hz
1280x1024 60 Hz
1280x800 60 Hz
1280x720 60 Hz
Resolution Refresh Rate Max.
1280x1024 75 Hz
1152x870 75 Hz
1024x768 60 Hz, 70 Hz, 75 Hz, 87 Hz
832x624 75 Hz
800x600 56 Hz, 60 Hz, 72 Hz, 75 Hz
720x400 70 Hz, 88 Hz
640x480 60 Hz, 67 Hz, 72 Hz, 75 Hz
