NXA-WAP1000 Smart Wireless Access Point
3
NXA-WAP1000 Smart Wireless Access Point
Power
The AP does not have a power switch. It utilizes Power Over Ethernet (PoE), which draws power from its Ethernet
connection. An optional power supply (FG2255-61) may also be used in circumstances where PoE is not available, via
the External Power port (FIG. 2).
Ethernet Ports
The access point has two 10BASE-T/100BASE-TX RJ-45 ports and one 10/100/1000 RJ-45 port that can be attached
directly to 10BASE-T/100BASE-TX LAN segments. These segments must conform to the IEEE 802.3-2005
specifications.
These ports supports automatic MDI/MDI-X operation, so you can use straight-through cables for all network
connections to PCs, switches, or hubs.
NXA-WAP1000 (FG2255-51/53) Specifications (Cont.)
Front LED Indic at ors (Cont .)
5G: • Off: The WLAN service is down.
• Amber: The WLAN service (or mesh network) is up and at least one wireless
client is associated, but RSSI is low. If mesh networking is enabled, at least
one downlink MAP is connected.
• Green: The wireless WLAN service (or mesh network) is up and at least one
wireless client is associated. If mesh networking is enabled, at least one
downlink MAP is connected.
• Fast flashing green (two flashes every second): The WLAN service (or mesh
network) is up, but no wireless clients or downlink MAPs are currently
associated.
• Slow flashing green (one flash every two seconds): The WLAN service is up,
no wireless clients are currently associated, mesh networking is enabled and
at least one downlink MAP is connected.
Re a r Com pone nt s:
OPT: • Not active at this time.
Hard Reset: • Pressing, and then quickly releasing this internal button reboots the
NXA-WAP1000.
• Pressing and holding it for six seconds resets the NXA-WAP1000 to factory
default settings.
10/100 Ports (2): • Two RJ-45 ports for 10/100Mbps connections.
10/100/1000 PoE Port: • One RJ-45 port for a 10/100/1000 PoE (Power over Ethernet, 802.3af)
connection.
External Power Port: • Connects a power supply (12 VDC/1.25A) to this port. Power may also be
supplied via the 10/100/1000 PoE (802.3af) port.
Operating Temperature: • Operating: 0 to 40 °C (32 to 104 °F)
• Storage: -20 to 70 °C (32 to 158 °F)
Operating Humidity: 15% to 95% (non-condensing)
Certifications: • FCC
•IC
•CE
•C-Tick
•RoHS
Included Accessories: • Category 5 (CAT5e) network cable
• NXA-WAP1000 Installation Guide (93-2255-51)
• Mounting Template (93-2255-55)
• #4 sheet metal mounting screws (2) with molly bolts (2) for wall installation
Other AMX Equipment: • NXA-WAP1000 Power Supply (FG2255-61)
• NXA-ENET8-2POE PoE Switch (FG2178-63)
• NXA-WAPZD1100 Wireless LAN Zone Director (FG2255-75)
