Y AXIS: INPUTS
VCO1 SYNC
Sync audio in to VCO1.
VCF A
Audio input to the filter.
RM Y
This is the audio input to the ring mod.
The other audio input to the ring mod is hard wired from VCO3.
VCF CV
Frequency cut off CV input.
VCO3 CV / VCO2 CV / VCO1 CV
Pitch CV inputs for each oscillator.
VCO1 PW
CV input to control the pulse width of VCO1.
————
EXT1 / EXT2
Although these two options are on the X axis, they are actually inputs and / or
outputs.
These provide a way to connect the patch points to the outside world via 3.5mm jack
sockets.
