Battery Tester BA101 User Manual
9
BA101
Rippl
e
T
est
95mV 14
.3
2V
Normally, cranking voltage value lower than 9.6V is regarded as abnormal and it is ENTER if it is higher than 9.6V.
Test result of the tester includes actual cranking voltage and actual cranking time.
When cranking test is abnormal, battery test result will also be displayed at the same time.
This is for the convenience of the maintenance personnel to quickly know the whole state of the starting system according to the data.
After testing finished, do not shut down the engine, press ENTER key to enter Charging Test.
3.2.3
Charging System and Ripple Test
When enter the charging test, please choose "Charging Test?"
Press ENTER key again to start the charging test.
NOTE: Do not shut down the engine during the test. All electrical appliance and device are in OFF state. Turn on/off any electrical appliance
in the vehicle during the test will affect the accuracy of the test result.
Tester will do the following tests in a sequence:
For ripple test, tester will display the real time ripple and meanwhile, shows ripple volt and charging volt values at the bottom line.
It takes approx. 6 seconds for the ripple test.
After the ripple test, tester will automatically start the loaded voltage test.
Loaded Volt Test takes approx. 3 seconds, then it hints "Step on accelerator to increase engine rotating speed"
Char
ging
T
est
Loaded
T
esting
****
T
est
in
Ve
hicle
1.Battery T
e
st
2.Cranking
T
es
t
3.Charging
T
e
st
Cran
king
T
est
T
imes
Cranking
Replace
1020ms
Low
10.13V
Cran
king
T
est
T
imes 780ms
Cranking Normal
10.13V
Cran
king
T
est
RPM Detected
ANCEL
To Next Page
