BA101
Main Menu
1.Quick T e st
2.Battery in Vehicle
3.Out of V ehicle
4.Review Data
5. Print Data
6.System Setu p
2) Good, Recharge
Good battery but low current, recharge before using.
3) Replace
The battery is near to or already reached the end of the using life, replace battery, otherwise, bigger danger will be followed.
4) Bad Cell, Replace
Battery interior damaged, bad cell or short circuit, replace battery.
5) Charge, Retest
Unstable battery shall be recharged and retested to avoid error. If same test result appears after recharge and retest, the battery is regarded
as damaged, replace the battery.
Battery In-Vehicle or Battery Out-Of-Vehicle
Press UP/DOWN key to select the battery location, in vehicle or out of vehicle, then press ENTER key to confirm.
Battery in vehicle means battery is connected with vehicle generator or vehicle electrical appliance.
3.2 Battery in vehicle
Choose the battery in vehicle and press Enter key, then it will enter the below menu.
Healthy : 39% 310CCA
Charge:20% 12.08V
Internal R=30.1m Ω
Rated: 500A
CHARGE-RETE ST
Heal t hy : 0% 0CC A
Charge:20% 10.64V
Internal R=45.2m Ω
Rated: 500A
BAD CELL，REPLACE
Healthy : 78% 440CCA
Charge:30% 12.20V
Internal R=7.2m Ω
Rated: 500A
GOOD, RECHARGE
Healthy : 46% 490CCA
Charge:80% 12.68V
Internal R=18.1m Ω
Rated: 500A
R EP L A C E
