Battery Tester BA101 User Manual
7
BA101
EN： European Automobile Industry Association Standard
SAE: Society of Automotive Engineers Standard
GB: China National Standard
Rating range as following:
Measure Standard Measure Range
CCA 100-2000
BCI 100-2000
CA 100-2000
MCA 100-2000
JIS 26A17--245H52
DIN 100-1400
IEC 100-1400
EN 100-2000
SAE 100-2000
GB
Input correct test standard and rating, press ENTER key, tester starts to test, and dynamic interface "TESTING" prompted. See below:
It takes around 3 seconds to display the battery test result.
Battery Test Result
Battery test result includes 5 types as following:
1) Good Battery
The battery is without any problem, please be relaxed to use!
Setting Rate
500
CC
A
Se le ct Input
CCA
Healthy : 96% 490CCA
Charge:98% 12.64V
Internal R=6.1m Ω
Rated: 500A
GOOD BATTERY
100-2000
