Configured for
all models
While set up the unit, the Smoke Delivery Hose
need to be mounted onto the Smoke Outlet .
Smoke Outlet Port
Configured for
all models
While set up the unit, the power cords need to
plug into the power socket.
Power Socket
Configured for
all models
While set up the unit, smoke oil need to be filled
into the unit, do not exceed the MAX line.
Check and confirm proper oil level periodically. If
the oil level is lower than the MIN line,the unit would
need a refill.
Oil Level Gauge
Configured for
certain models
The Pressure Gauge displays the output pressure
of the machine if block the smoke outlet port,
otherwise it shows the real time pressure of the
system been testing.
Pressure Decay Test: This gauge can also be used
to determine if a leak exists by switching off the <Air
Control> while the system is under pressure. If the
gauge holds the displayed pressure, there is no
leakage. If the displayed pressure starts drops,
there is leakage in the system.
The purpose of the flow meter is to provide a quick
visual indication of the amount of air/smoke
passing through the system being tested. If the
smoke nozzle is in a closed system, and there are
no leaks Configured for certain modelsin that
system, the flow meter will read zero (ball at bottom
of scale). As the system is filled with air or smoke,
the ball in the flow meter will slowly fall to the
bottom of the scale as the pressure in the system
equalizes to the output pressure of the unit. As the
flow decreases, the output pressure will increase. If
the flow meter ball never falls to the bottom of the
scale, there is leakage or air passing through the
system. It is not necessary to use smoke when
using the flow meter to determine if a leak exists.
System Pressure
Gauge
Configured for
certain models
Configured for
certain models
Short press the switch button to set the displayed
pressure unit according to the reading preference,
there are 4 kinds of pressure unit available, psi, bar,
kpa, kg/m2. Long press the switch button for 3
seconds to make the displayed pressure value zero.
Digital Pressure
Gauge
Flow Meter
