CONVERSION TO LP/PROPANE GAS
Every cooktop is provided with a set of injectors for the various types of gas.
Select the injectors to be replaced according to the table below. The nozzle diameters, expressed
in hundredths of a millimetre, are marked on the body of each injectors.
Attention: the regulator is pre adjusted for both values. Aside from the turning of the plug (1),
there is no further customer adjustment necessary
Pressure regulator series RV ...C
natural / town gas adjustment
(low outlet pressure)
Pressure regulator series RV ...C
LPG adjustment (high outlet
pressure)
fig. 5.3
SETTING THE PRESSURE REGULATOR (Fig. 5.3)
